The X3 MAX is equipped with a 28-inch dual-shock hydraulic front fork with 6 inches of suspension travel, delivering a 30% improvement in both performance and comfort compared to the X3. The rear suspension has also been upgraded with a 13-inch mid-mounted shock, offering 5 inches of travel and a 1000 lbs spring rate.
Top Speed 45 Mph
Adjustable with 3 Speed Modes
Motor 6500W
Mid-Mounted Motor
17"*3.0 × 14"*3.0
Puncture-Resistant Tires
60V 28AH
Battery Capacity
Range 55 Miles
Single Charge Range
260 Nm
Max 70° Gradient
Free Accessories
Order now and receive a free Front Number Plate, a Head Light total value of $137
$39.00
FREE
$98.00
FREE
Built for Off-Road Adventures
Premium Handling Experience
6500W Mid-Drive Motor
The X3 MAX features a custom high-performance Bafang mid-drive motor, supporting peak controller phase current up to 180A.
With an IP67 waterproof rating, the motor coils and Hall sensors can withstand temperatures up to 356℉, delivering exceptional thermal resistance and operational stability.
Through the highly efficient synergy of the controller, battery, and motor system, total system output reaches an impressive 6500W of peak power.
High-Capacity Battery
Equipped with a 60V 28Ah (1680Wh) lithium battery, delivering a maximum discharge current of up to 120A. When fully charged, the battery reaches 67.4V.
Integrated with an advanced BMS (Battery Management System) featuring intelligent temperature monitoring and multi-layer protection to ensure enhanced safety and long-term reliability.
The system also includes anti-spark charge and discharge ports for safer operation. The complete battery assembly is fully certified and compliant with ROHS, CE, UN38.3, and MSDS standards.
- Suspension System - Fully Upgraded
- Dual-Piston Hydraulic Brakes
- Lighting System
- 420-60T Cast Sprocket
- 17"*3.0 × 14"*3.0 AT Tires
- Full-Twist Throttle
Vehicle Specifications
| Electric-Only Range | Single Charge 55 Miles |
|---|---|
| Top Speed | Up to 45 Mph |
| Dimensions | 55.12"L × 12.6"W × 24.8"H |
| Max Load Capacity | 350 Lbs |
| Ebike Net Weight | 130 Lbs |
| Torque | 260 Nm |
Electric Motor Control
| Battery | 60V*28Ah IP65 |
|---|---|
| Power mode | 3 Speed Mode |
| Motor | 6500W Mid-Drive Bafang Motor |
| Controller | 60V/85A |
| Peak Efficiency | 95.3% |
Frame Assembly
| Body color | Black |
|---|---|
| Front Suspension | Total Length 28" |
| Rear Suspension | Total Length 10" |
| Handlebar | Total Length 28" |
| Chain | 420-126 |
What's in the box
| Tool Kit | 1 PCS |
|---|---|
| Tires | 2 PCS |
| Fender Kit | 1 PCS |
| Key | 1 PAIR |
| Charger | 1 PCS |
| Front Number Plate | 1 PCS |
|
|
Vehicle Details
| Terrain | Off-road |
|---|---|
| Trail Riding Style | Off-road |
| Intended Use | Recreation |
| Suspension | Full Suspension |
Main Differences
3S helps you quickly find the bike that’s right for you.
| Field name |
Sale Price
$1,299.00
Regular Price
|
Sale Price
$949.00
Regular Price
|
Sale Price
$1,399.00
Regular Price
|
|---|---|---|---|
|
|
|
| |
| Peak Power |
6500W
|
3500W
|
7000W
|
| Tire |
17"*3.0 × 14"*3.0
|
14"*3.0 × 12"*3.0
|
17"*3.0 × 14"*3.0
|
| Top Speed |
45 Mph
|
40 Mph
|
50 Mph
|
| Torque |
260NM
|
220NM
|
300NM
|
| Max Range |
55 Miles
|
50 Miles
|
60 Miles
|
| Suitable Height |
5'1" to 6'5"
|
4'2" to 6'0"
|
5'1" to 6'5"
|
Our commitment
FAQs
Find quick answers to common questions
Pre Sale
1. Does my height suit the X3 MAX
The recommended rider height is 5'1" - 6'5".
2. Do I need to assemble the bike?
We have already assembled 90% of the bike. You just need to tighten the wheel bolts, install the fender, and attach a few small components, and you'll be ready to go.
3. Why did I buy two e-bikes but only receive one tracking number or have them arrive at different times?
Since each e-bike is shipped separately, it’s possible that due to the shipping carrier, they may arrive at different times. Please don’t worry. If you have any questions, feel free to contact our customer service department for the latest updates.
4.What’s the Difference Between the X3 and X3 MAX?
Range
X3: Equipped with a 60V 22.5Ah battery, with a single-charge range of up to 50 miles.
X3 MAX: Equipped with a 60V 28Ah battery, with a single-charge range of up to 55 miles.
Power
X3: Equipped with a 3500W motor, with a top speed of up to 40 mph.
X3 MAX: Equipped with a 6500W motor, with a top speed of up to 45 mph
Maintenance & Accessories
1. Daily Maintenance
After heavy use, it’s recommended to clean and lubricate key components such as the chain, hubs, and suspension. For long-term storage, make sure to inflate the tires to prevent deformation.
2. Battery Maintenance
If not in use for an extended period, store the battery in a cool, dry place. Disconnect the cables to avoid excessive discharge, and charge the battery at least once every two months, keeping it between 60% and 80% charged.
3. Can Replacement Parts or Accessories Be Purchased Separately?
Yes, we offer compatible accessories and replacement parts. If you are using third-party modification parts, please ensure their compatibility with our products.
Policy
1. What's your warranty policy?
Leonx offers a one-year warranty on all e-bikes, for more specific warranties, please check our warranty policy.
2. What's your return policy?
Customers are allowed to submit a return request within 7 days of delivery via service@leonx.com. For more specific return and refund, pls check our return policy.
3. What's your shipping policy?
Time of arrival includes order processing time and shipping time (3-8 working days).you can check more details on our Shipping Policy Page
